MPrint

Screen Shot 2023-08-13 at 4.36.59 PM

One Click Metal introduces the MPRINT, a cutting-edge 3D Printer from their ‘BOLD SERIES,’ designed with a focus on accessibility for industrial prototyping and low-volume series production applications. Featuring a new 200W fiber laser and Galvo scanner, this system ensures enhanced productivity and long-term reliability. Its build volume of 150mm x 150mm x 150mm, coupled with an inert nitrogen gas outlet, enables compatibility with various metals like stainless steel, aluminum, and soon-to-be-introduced tool steel – all conveniently provided by One Click Metal. The MPRINT’s user-friendly supply cartridge system allows easy handling of powdered feedstock in modular canisters, with five cartridge slots, each accommodating up to 8.5kg of material, resulting in 250% oversupply compared to the build volume, leading to reduced material changes and minimal downtime. Additionally, RFID tags on each cartridge enable users to monitor fill levels effortlessly and prevent accidental mixing of incompatible metals. For those new to 3D printing, One Click Metal offers a comprehensive Guide to Metal 3D Printing, covering various printing technologies, their benefits, limitations, and essential design considerations and post-processing techniques. Explore their range of top-quality metal printing powders to materialize your ideas with unmatched precision and quality today!

In the holistic process chain, MPrint is step 3; Once the MPRINT+ has been set up for printing, following the machine operation guidelines, you are ready to begin the build job.

Technical Specifications

Powder Supply

  • 5 supply cartridges
  • 250% oversupply of the build volume (at maximum capacity)

Process chamber

  • LPBF-process (learn more)
  • X-profile powder application
  • 200W laser power (fiber)
  • 70µm focus diameter
  • up to 3000mm/s scanning speed

Build module

  • 150mm x 150mm x 150mm
  • 20-80µm layer height

Connection and consumption

  • Power supply: 230V/50-60Hz (US: 110V)
  • Fuse protection: 16A
  • Inert gas: Nitrogen

Dimensions and weight

  • Dimensions WxHxD: 1,1 x 1,9 x 0,79m
  • Weight: 440kg

Additional Resources

Product Flyer

Manufacturer: One Click Metal
